4

I'm not sure what's caused it. I haven't changed any system settings. The only thing I've done that may have broken something is updating my software.

My update was:

upgrade linux-generic-hwe-20.04:amd64 5.8.0.48.54~20.04.32 5.8.0.49.55~20.04.33
upgrade linux-image-generic-hwe-20.04:amd64 5.8.0.48.54~20.04.32
upgrade linux-headers-generic-hwe-20.04:amd64 5.8.0.48.54~20.04.32
upgrade linux-image-extra-virtual:amd64 5.4.0.70.73 5.4.0.71.74
upgrade linux-image-generic:amd64 5.4.0.70.73 5.4.0.71.74
upgrade linux-libc-dev:amd64 5.4.0-70.78 5.4.0-71.79
upgrade libseccomp2:amd64 2.4.3-1ubuntu3.20.04.3 2.5.1-1ubuntu1~20.04.1
upgrade nomachine:amd64 7.3.2-3 7.4.1-3```

Removing nomachine did not solve the problem.

It was far worse before, I'm not sure how to describe exactly, but my entire screen's UI was glitching out. So I rebooted and that stopped, but now the terminal text looks like this:

glitched terminal text

I haven't changed any terminal settings. This seems to be occurring in the entire OS. Here is another example:

flickering dock

Not sure how to go about troubleshooting this? I don't have the time to reinstall the OS, nor do I think I should have to because this is just ridiculous and shouldn't happen. I'm not aware of anything I've done to make the system unstable.

Edit

Earlier I also tried booting the PC. It failed and got stuck on some command in a terminal (didn't manage to take a photo of what it said).

So I rebooted into recovery mode with both available kernels. I was getting strange glitches like this:

dialog text disordered, colours mixed up

That didn't work. So I rebooted the PC normally, and now I somehow logged in fine. Now I'm getting popups saying to report a system error. It says this:

report error with bluetoothd

Environment

  • Ubuntu 20.04.2 LTS
  • GNOME 3.36.8
sudo lshw -class display
  *-display
       description: VGA compatible controller
       product: Xeon E3-1200 v3/4th Gen Core Processor Integrated Graphics Controller
       vendor: Intel Corporation
       physical id: 2
       bus info: pci@0000:00:02.0
       version: 06
       width: 64 bits
       clock: 33MHz
       capabilities: msi pm vga_controller bus_master cap_list rom
       configuration: driver=i915 latency=0
       resources: irq:33 memory:f7800000-f7bfffff memory:e0000000-efffffff ioport:f000(size=64) memory:c0000-dffff

I also did MemTest86, which passed with 0 errors.

Let me know if more details are required.

Zanna
  • 70,465
Daniel
  • 446
  • More info and possible source of the problem: https://www.reddit.com/r/Fedora/comments/9983xl/beginner_heavy_flickering_after_kernel_update_amd/ – Luigi Pirelli Apr 18 '21 at 06:43
  • Check your Displays settings panel, and tell me what choices you show for Refresh rate. – heynnema Apr 22 '21 at 15:15
  • Launchpad bug report: https://bugs.launchpad.net/ubuntu/+source/linux-meta-hwe-5.8/+bug/1924624 - anyone having this problem can add yourself as affected – Zanna Apr 24 '21 at 09:03
  • See also https://askubuntu.com/questions/1344765/highlight-diagonal-tears-with-intel-graphics-ubuntu-20-04/1349434#1349434 Reverting to 5.4 kernel resolved my issue – Paul Dev Jul 01 '21 at 20:15

3 Answers3

8

The -49 and -50 kernels are flawed, and have been withdrawn. There are graphics issues (possibly only with internal Intel video subsystems).

Boot your computer. At the GRUB menu, select the 2nd choice, Advanced Options (or some such), and select your -48 kernel, or earlier if you don't have -48, and run off of that for now.

Keep up to date with Software Updater and once you see the -51 kernel, or later, then select it at next boot.

Update #1 (for @dspacejs):

Start Synaptic and install these files (search for 5.8.0-48)...

enter image description here

Run:

ls -al /boot

Confirm that initrd.img-5.8.0-48-generic is there.

If it's not there, then run:

sudo update-initramfs -c -k 5.8.0-48-generic

Then:

sudo update-grub
reboot

At the GRUB menu, select Advanced Options, then select the -48 kernel to boot from.

heynnema
  • 70,711
  • Yesterday my OS/laptop began having serious issues(wifi,bluetooth,sound,ethernet and etc not working), and in last I found out it has happened by the -49 kernel, so, Just reported the bug and I'm , using -48 from grub menu from then – Parsa Apr 17 '21 at 15:24
  • running with 50 version now without problem, but problem can arriva later changin refresh rate as discovered in https://www.reddit.com/r/Fedora/comments/9983xl/beginner_heavy_flickering_after_kernel_update_amd/ – Luigi Pirelli Apr 18 '21 at 06:43
  • I'm having the issue in 5.8.0-59-generic – isapir Jun 27 '21 at 22:02
  • @isapir Please start a new question. – heynnema Jun 27 '21 at 22:12
0

I was having the same issue as of late June 2021 with Kernel version 5.8.0-59-generic. Since the issue has been around for 10 updates now it looks like it isn't given a high priority, so I switched from Xorg to Wayland which doesn't suffer from that issue.

To do that, while logged out, select the username, click the settings cog on the bottom right and choose "Ubuntu on Wayland" instead of "Ubuntu". Then log in.

If you don't have that option then edit /etc/gdm3/custom.conf and make sure that the line WaylandEnable=false is commented out (changes to that file require sudo systemctl restart gdm3 to be applied)

isapir
  • 513
0

Same issue experienced, see also Highlight Diagonal Tears with Intel Graphics (Ubuntu 20.04)

I reverted to the 5.4 kernel revision which has rectified the issue

Paul Dev
  • 11
